All Spec

PANEL

• Screen Size (Inch)


  43"
• Panel Technology


  ADS
• Back Light Type


  Edge
• Aspect Ratio


  16:9
• Native Resolution


  3840 x 2160 (UHD)
• Refresh Rate


  60Hz
• Brightness


  500nit (Typ.)
• Contrast Ratio


  1,200:1 (Typ.)
• Dynamic CR


  1,000,000:1
• Color Gamut


  BT709 95%
• Viewing Angle (H x V)


  178 X 178
• Color Depth (Number of Colors)


  10bit(D), 1.07Billion colors
• Response Time


  8m (G to G) (Typ.)
• Surface Treatment (Haze)


  25%(Typ)
• Life time


  50,000Hrs (Min.)
• Operation Hours (Hours/Day)


  24/7
• Portait / Landscape


  Yes / Yes
• Transparency


  NO
• QWP (Quarter Wave Plate)


  N/A

CONNECTIVITY

• HDMI In


  Yes(3), 3840x2160@60Hz, HDCP 2.2/1.4
• HDMI In (HDCP Ver.)


  2.2/1.4
• DP In


  Yes(1), 3840x2160@60Hz, HDCP2.2/1.3
• DVI-D In


  NO
• RGB In


  NO
• Audio In


  NO
• RS232C In


  Yes (1), 4pin Phone-jack
• RJ45(LAN) In


  Yes (1)
• IR In


  Yes (1)
• USB In


  USB2.0 Type A(2)
• HDMI Out


  NO
• DP Out


  NO
• Audio Out


  Yes (1)
• Touch USB


  NO
• External Speaker Out


  NO
• RS232C Out


  Yes (1), 4pin Phone-jack
• RJ45(LAN) Out


  NO
• IR Out


  No (Support IR daisy chain via RS232C IN/OUT)
• Daisy Chain


  NO

MECHANICAL SPECIFICATION

• Bezel Color


  Black
• Bezel Width


  Even bezel : 11.4mm
• Weight (Head)


  9.4 kg
• Packed Weight


  11.3 kg
• Monitor Dimensions (W x H x D)


  971.7 x 561.0 x 29.7mm
• Monitor Dimension with Stand (W x H x D)


  N/A
• Handle


  NO
• VESA Standard Mount Interface


  200 x 200
• Carton Dimensions (W x H x D)


  1055.0 x 660.0 x 140.0mm
• Weight (Head+Stand)


  N/A

FEATURE - HARDWARE

• Internal Memory (eMMC)


  16GB
• Wi-Fi/BT (Built-in)


  Yes
• Temperature Sensor


  Yes
• Auto Brightness Sensor


  Yes(Built-in for Europe only, sold separately in other regions)
• Pixel Sensor


  NO
• Proximity Sensor


  NO
• Current Sensor


  NO
• BLU Sensor


  NO
• Humidity Sensor


  NO
• Acceleration(Gyro) Sensor


  Yes
• Power Indicator


  NO
• Local Key Operation


  Yes
• FAN (Built-in)


  NO

FEATURE - SOFTWARE

• OS Ver. (webOS)


  webOS8.0
• Local Contents Scheduling


  Yes
• Group Manager


  Yes
• USB Plug & Play


  Yes
• Fail over


  Yes
• Booting Logo Image


  Yes
• No Signal Image


  Yes
• RS232C Sync


  Yes
• Local Network Sync


  Yes
• Backlight Sync


  NO
• PIP


  Yes
• PBP


  Yes (4)
• Screen Share


  Yes
• Video Tag


  Yes (4)
• Play via URL


  Yes
• Screen Rotation


  Yes
• External Input Rotation


  Yes
• Gapless Playback


  Yes
• Tile Mode Setting


  Yes (Max. 15x15)
• Setting Data Cloning


  Yes
• SNMP


  Yes
• ISM Method


  Yes
• Auto Set ID


  Yes
• Status Mailing


  Yes
• Control Manager


  Yes
• Cisco Certification


  YES
• Crestron Connected


  Yes
• Smart Energy Saving


  Yes
• PM mode


  Yes
• Wake on LAN


  Yes
• Network Ready


  Yes
• Beacon


  Yes
• HDMI-CEC


  Yes
• SI Server Setting


  Yes
• webRTC


  Yes
• Pro:Idiom


  Yes
• Brightness Compensation


  NO
• W/B Setting by Grey scale


  NO
• Scan Inversion


  NO

ENVIRONMENT CONDITIONS

• Operation Temperature


  0°C to 40°C
• Operation Humidity


  10 % to 80 %

POWER

• Power Supply


  AC 100-240V~, 50/60Hz
• Power Type


  Built-In Power

POWER CONSUMPTION

• BTU (British Thermal Unit)


  222 BTU/Hr(Typ.), 423 BTU/Hr(Max)
• Smart Energy Saving (70%)


  59W
• DPM


  0.5W
• Power off


  0.5W
• Max.


  124W
• Typ.


  65W

SOUND

• Speaker (Built-in)


  Yes (10W X 2)

CERTIFICATION

• Safety


  CB / NRTL
• EMC


  FCC Class "B" / CE / KC
• ERP / Energy Star


  Yes / Yes
• ePEAT(US only)


  YES

OPS COMPATIBILITY

• OPS Type compatible


  N/A
• OPS Power Built-in


  N/A

SOFTWARE COMPATIBILITY

• SuperSign CMS


  Yes
• SuperSign Control+


  Yes
• SuperSign WB


  Yes
• SuperSign Cloud


  Yes
• Promota


  NO
• Mobile CMS


  Yes
• Connected Care


  Yes

LANGUAGE

• OSD


  English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic, Polski

ACCESSORY

• Basic


  Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender, Cable Holder (For Power Cord), IR/Light sensor receiver(EU/EK Only), Magnetic sheet(2EA, EU/EK Only)
• Optional


  Slim Wall Mount (WB21LMA/B), Normal Wall Mount (LSW240A/B), IR/Light sensor receiver (ACC-L)

SPECIAL FEATURE

• Overlay Touch Compatibility


  N/A
• Smart Calibration


  N/A
• Tilt (Face up)


  N/A
• Tilt (Face down)


  Max. 15 degree (40℃ temperature)
• IP Rating


  IP5X
• Conformal Coating (Power Board)


  Yes (Partial space coating)
• Power Protection


  N/A
• Direct Sunlight


  N/A
